LW39-25-Cam Switch-Siemens APT

LW39-25

Ideal for the places with greater capacity, especially suitable for the DC application environment. Rolling bearing is used inside for soft and gentle touch and long mechanical endurance.

Important Parameters

Rated Insulation Voltage Ui:

690V
Rated Thermal Current Ith:

25A
Working Alternating Current

AC-15:220V/12A 380V/8A
AC-3:380V/12A
AC-4:380V/10A
AC-21:380V/25A
AC-22:380V/25A
Working Direct Current

DC-13:110V/2.5A 220V/1.25A

Product Features

The built-in wiring is safe and reliable.

Operating angle 30°, 45°, 60°, 90°

Max. number of nodes in contact system is 12 and no more than 8 is recommended

Technical Parameters

Main Parameters

Rated Insulation Voltage Ui:	690V
Rated Thermal Current Ith:	25A
Working Alternating Current	AC-15:220V/12A 380V/8A、AC-3:380V/12A、AC-4:380V/10A、AC-21:380V/25A、AC-22:380V/25A
Working Direct Current	DC-13:110V/2.5A 220V/1.25A
Power Frequency Withstand Voltage	2500V, 1min
AC Endurance	200,000 times
DC Endurance	100,000 times
Mechanical Endurance	300,000 times
Degree Of Protection For Head	IP40
Altitude	Not more than 2,000m
Ambient Temperature	-25℃～+55℃
Relative Humidity Of Air	Not more than 90%
Mounting Category	Ⅲ
Pollution Degree	3
