PB1J (Φ22mm)
Aesthetic, delicate, compact and reliable.
-
Rated insulation voltage
AC 300V
-
Rated thermal current
5A
-
Electrical Endurance
100,000 times/AC-15 6A/230V
-
Degree Of Protection
IP65
Product Features
Mounting cut-outs: φ 22.5mm
Six colors – red, green, yellow, blue, white and black
Integrated design is adopted for head and contact to achieve compact structure.
Technical Parameters
Main Parameters
|
Rated Insulation Voltage |
AC300V 50Hz |
|
Power Frequency Withstand Voltage |
AC1500V |
|
Mechanical Endurance |
300,000 times |
|
Electrical Endurance |
100,000 times/AC-15/DC-13 230V/5A 24V/6A |
|
Ambient Temperature |
-25℃～70℃ |
|
Storage Temperature |
-40℃～80℃ |
|
Certificate |
CCC、CE、RoHS |
|
Degree of Protection |
IP65 |
|
Rated Thermal Current |
5A |
Industry Application
-
Rail TransitEnhancing urban traffic with smart solutions to deliver a high-quality travel experience
-
New EnergyPromoting the utilization of renewable energy, assisting in the transformation to clean energy
-
LogisticsAssisting in the intelligence of logistics management systems, improving transportation efficiency and traceability
